Server Racks
- Made of 1.2mm/1.6 mm high quality metal sheet
- Mounting angle 2mm MS with clear "U" marking
- Front wiht toughened glass, Rear MS door with lock
- Optional perforated front & back doors also available
- Removable side panels
- Cable entry provision at top & bottom
- 2/4 Cooling fan fitting option at top
- Sufficient perforation provided for ventilation
- Finished with 7 process pre-treated powder coating
- Attractive color design- RAL-7035 or black
Server Racks Available in below variant:-
| S.N | PART CODE | SIZE | DIMENTIONS (W*D*H) |
|---|---|---|---|
| 1 | DR-FS-27U-1000 | 27U | 600 X 1000 X 1269 |
| 2 | DR-FS-32U-800 | 32U | 600 X 800 X 1492 |
| 3 | DR-FS-32U-1000 | 32U | 600 X 1000 X 1492 |
| 4 | DR-FS-37U-800 | 37U | 600 X 800 X 1715 |
| 5 | DR-FS-37U-1000 | 37U | 600 X 1000 X 1715 |
| 6 | DR-FS-42U-800 | 42U | 600 X 800 X 1938 |
| 7 | DR-FS-42U-1000 | 42U | 600 X 1000 X 1938 |
| 8 | DRFS-42USR800 | 42U | 800 x 800 x 1938 |
| 9 | DR-SR-42U-1000 | 42U | 800 X 1000 X 1938 |
Optional Accessories:-
- Fan Tray with 4 Fan
- ACD-6 Socket 5 Amp
- ACD-5 Socket 5/15 Amp
- ACD- 10 Socket 5 Amp/15 Amp
- Cable Manager 1U MS/PVC- Horizonal
- Cable Manager 1U MS/PVC- Vertical
- Stationary Shelf
- Sliding Keyboard Tray
- Hardware Packet
